Freestanding Enclosure Swing Out Frames for 19" Rack
Mounting
Formed from 10 gauge steel, frames are drilled and tapped to EIA
requirements for mounting standard 19" rack accessories.
Designed for installation in 72" and 90" high enclosures. The swing frame
pivots on 0.5" pins within the enclosure for easy access to the rear of rack
mounted equipment.
The frame positions at any depth within the enclosure and is fastened in
the closed position with quarter turn fasteners.
Swing frames may be mounted in 30" and 36" wide enclosures, or in 60"
and 72" wide enclosures with an optional center panel support.
One or two frames may be mounted in 30" and 36" wide enclosures with
dual access, and 1,2,3 or 4 frames may be mounted in 60" and 72" wide
dual access enclosures.
Finished in black.
Enclosure
Width
Single
Part No.
A
B
C
Height
Door
1418SFYY 78.50 31.80 12.14
90.00
36.00
1418SFY
1418SFX
60.50 31.80 12.14
60.50 25.82 6.14
72.00
72.00
36.00
30.00
